Ercolina TB180 Top Bender

The Ercolina TB180 is the largest Top Bender, for tube up to 6 in (.120 wall), Schedule 40 pipe up to 6 in and square tube up to 4 in. It has touchscreen programming, a hand-held remote and a heavy-duty steel gear case, with radii up to 31-1/2 in with the case extension. Call Icon Machine Tool at (816) 300-0019 for a quote.

Category:

Description

Key Features

  • Touchscreen programming: sets bend angle, with system diagnostics in multiple languages and unlimited program storage with USB.
  • Springback compensation: with a digital display of bend angle.
  • Hand-held remote: controls bend, return and emergency stop.
  • Quick-change tooling: with multiple radii available.
  • Counterbending die: position monitored electronically for accuracy and repeatability.
  • Heavy-duty steel gear case: with an optional hydraulic clamping system.

Specifications at a Glance

  • Tube: up to 6 in, .120 wall
  • Pipe: up to 6 in Sch. 40
  • Square tube: up to 4 in, .250 wall
  • Centerline radius: as small as 3D; up to 23-1/2 in (31-1/2 in with the case extension)
  • Power: 480V 3-phase

Who It’s For

Fabricators and pipe shops bending large pipe and tube up to 6 in.

Sales & Service from Icon

Icon Machine Tool sells Ercolina machines across Missouri, Kansas, Oklahoma, Arkansas, eastern Iowa, Indiana, Illinois, Oregon and Washington. Our team helps you choose the right machine and configuration for the parts you make.

Ercolina Catalog Page (PDF)  Talk to a Specialist: (816) 300-0019
