Description
Key Features
- Miters to 60°: the column and blade tilt up to 60° left and right; powered tilt is optional.
- 3° canted column: a standard 3° forward approach angle for faster cutting of structural material.
- Automatic stops: adjustable stops can be preset to stop the blade’s advance and return, and to stop the motor anywhere in the 18 in of blade travel.
- Quick-action vise: 6 in high x 12 in wide jaws that shift to either side of the blade.
- T-slotted work table: 24.25 x 33 in work area at 38 in high, with two machined T-slots.
- Front-mounted speed control: blade speed adjusts from the operator’s station, 50 to 450 ft/min by inverter.
- Chip and coolant cleanup: a flushing hose washes chips from hard-to-reach places, and a power chip brush works with blade wipers and flood coolant to keep the teeth clear.
Specifications at a Glance
- Capacity at 0°: 17.5 in round; 17.5 x 22 in rectangular
- Capacity at 45°: 17.5 x 14.5 in right; 17.5 x 13 in left
- Capacity at 60°: 17.5 x 9.7 in right; 17.5 x 7.3 in left
- Blade: 15 ft 4 in x 1.25 in x 0.042 in
- Motor and feed: 5 hp; clutch power feed, 0 to 250 lb feed force
Who It’s For
Fabricators cutting structural shapes and tube that need miters in both directions, with preset stops for repeat cuts.
Sales & Service from Icon
Icon Machine Tool sells Marvel machines across Missouri, Kansas, Oklahoma, Arkansas, eastern Iowa, Indiana, Illinois, Oregon and Washington. Our team helps you choose the right machine and configuration for the parts you make.
