Description
Key Features
- Built around the operator: the TruBend Series 7000 was the first bending machine with an ergonomics certificate. A sit/stand aid, adjustable support table and tilting control keep long runs comfortable.
- BendGuard Automatic: the control moves the safety light field to the height of the set-up tools on its own, so setup is fast and safe.
- ACB Wireless and ACB Laser: measure and correct the bend angle automatically. With ACB Speed, springback is measured only on the first part, saving up to 35% of cycle time.
- 6-axis backgauge: positions parts precisely, and the gauge finger shape handles very short flanges without collisions.
- Small footprint: fits into almost any shop layout and can be moved with a forklift.
- 2D code scanner: reads the bar code or Data Matrix code on the job paperwork and loads the right bending program.
Specifications at a Glance
- Press force: about 40 US tons (360 kN)
- Bending length: 40.2 in (1,020 mm)
- Width between columns: 36.7 in (932 mm)
- Usable open height and throat depth: 11.6 in (295 mm) and 5.9 in (150 mm)
- Footprint and weight: 74.8 × 52.8 in (1,900 × 1,340 mm), 7,275 lb (3,300 kg)
Who It’s For
Shops bending high volumes of small parts, up to about 40 in long, that want more output per operator from a press brake that takes little floor space.
Sales & Service from Icon
Icon Machine Tool is the TRUMPF sales partner for Missouri, Kansas, Oklahoma, Arkansas, eastern Iowa, Indiana, Illinois, Oregon and Washington. Our team helps you choose the right machine and configuration for the parts you make.
Full Specifications (PDF) Talk to a Specialist: (816) 300-0019
