Description
Key Features
- Built for heavy loads: crowning and the hydraulic upper and lower tool clamps are rated to 6,000 kN/m, for thick, short parts as well as long ones.
- Tandem operation: two machines work as one for bending lengths up to 52 ft (16 m).
- Room for tall parts: 880 mm (34.6 in) installation height and a 700 mm (27.6 in) stroke, and standard TRUMPF tools fit without adapters.
- Accurate angles on big parts: ACB Laser, ACB Wireless, Operator Controlled Bending (OCB) and Thickness Controlled Bending (TCB) keep angles right, even on large or thick workpieces.
- 6-axis backgauge: up to six CNC axes position parts precisely along the full length, with a heavy-duty version offering up to 39.4 in (1,000 mm) of travel.
- Lower tool displacement and station bending: two bending processes from one setup, and different tools side by side so several bends run without tool changes.
- Handling aids: bending aids and support brackets carry loads up to 661 lb (300 kg).
Specifications at a Glance
- Models and press force: TruBend 8230 to 81250, about 259 to 1,405 US tons (2,300 to 12,500 kN)
- Bending length: 127 to 317 in (3,230 to 8,050 mm), depending on model; up to 52 ft (16 m) in tandem
- Usable open height: up to 34.6 in (880 mm)
- Throat depth: 16.5 or 24.4 in (420 or 620 mm), depending on model
- Control: T-8000 S Multi-Touch Control
Who It’s For
Shops bending large, heavy, thick or tall parts that need high tonnage and long bending lengths without giving up precision.
Sales & Service from Icon
Icon Machine Tool is the TRUMPF sales partner for Missouri, Kansas, Oklahoma, Arkansas, eastern Iowa, Indiana, Illinois, Oregon and Washington. Our team helps you choose the right machine and configuration for the parts you make.
